Creamsource Vortex8 Soft RGB LED Light Panel Kit

The Creamsource Vortex8 Soft is a high-output 650W 2×1 RRGBBW LED fixture designed to produce a broad, naturally soft source without needing additional diffusion. Unlike the standard Vortex8’s concentrated 20° beam, the Vortex8 Soft features a wide 110° native beam, making it a great option for soft key light, fill, overheads, and large-area illumination. At 5600K, the fixture produces approximately 2,340 lux at 3 meters.

The Vortex8 Soft’s RRGBBW color engine provides a huge 2200K–15,000K CCT range along with green/magenta adjustment, HSI, XY, digital gels, direct RGBW control, and built-in effects. CRI and TLCI are both rated at a typical 95 for accurate skin tones and consistent color reproduction.

Eight independently controllable zones allow the Vortex8 Soft to be used for animated effects and more advanced lighting setups. For high-speed work, a dedicated mode provides flicker-free operation beyond 5,000 fps, with a sync input available for synchronizing the fixture directly to a camera shutter.

Built for demanding production environments, the Vortex8 Soft is IP65 weather resistant and features an integrated power supply, eliminating the need for a separate ballast. It can operate at full output from either AC or regulated 48V DC power, while integrated LumenRadio, DMX, Ethernet, and Bluetooth provide flexible wired and wireless control options.

Click Here for technical data.
